D-Link Fiber Optics Cable SM 6 cores 300 Meter | NCB-FS09x-UULS-06/3H

The D-Link NCB-FS09X-UULS-06/3H is a 6-core single-mode fiber optic cable designed for both indoor and outdoor installations. It features a central loose tube construction filled with a jelly compound for water resistance, surrounded by high-strength E-glass yarns for tensile strength. The cable is unarmored, making it lightweight and flexible, suitable for duct, aerial, and pipeline applications.

• Fiber Count: 6 single-mode fibers
• Fiber Type: Single-mode (G.652D)
• Core/Cladding Diameter: 9/125 µm
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Water Resistance: Jelly-filled loose tube with water-swellable yarns
• Strength Members: E-glass yarns
• Outer Sheath Color: Black
• Cable Diameter: Approximately 7.0 ± 0.5 mm
• Cable Weight: Approximately 60 kg/km
• Operating Temperature: -40°C to +60°C
• Storage Temperature: -40°C to +70°C
• Compliance: IEC 60794-1-21-E1, IEC 60794-1-21-E3, IEC 60794-1-21-E4, IEC 60794-1-21-E11, IEC 60794-1-21-E14, RoHS

This cable is ideal for high-speed data transmission in telecommunications and data center environments, offering reliable performance over long distances.
