| Standard&Protocol | IEEE802.3, IEEE802.3u, IEEE802.3ab |
| Interfaces | 1*10/100/1000Mbps WAN port |
| 3*10/100/1000Mbps LAN ports | |
| Antenna | 4*6dBi external antennas |
| Button | 1*WPS/Reset button |
| Power | Input：AC 100-240V~50/60Hz, 0.4A |
| Output：DC 9V⎓1A | |
| Dimension | 8.66 * 5.57 * 1.93 in (220*141.5*49mm) |
| LED Indicator | Sys*1,WAN*1, LAN*1,WiFi/WPS*1 |
| Wireless Standard | IEEE 802.11ac wave2/a/n 5GHz |
| IEEE 802.11b/g/n 2.4GHz | |
| Data Rate | 5GHz: Up to 867Mbps |
| 2.4GHz: Up to 300Mbps | |
| Frequency | Simultaneous dual band 2.4 & 5GHz |
| Transmission Power | CE: |
| <20dBm(2.4G) | |
| <23dBm(5G) | |
| FCC:<30dBm | |
| Basic Features | SSID Broadcast: Enable/Disable |
| Transmission Power: high, medium, low | |
| Beamforming | |
| MU-MIMO | |
| Wireless Security | WPA-PSK/WPA2-PSK, WPA/WPA2 |
| Wireless Security : Enable /Disable | |
| Internet Connection Type | PPPoE, Dynamic IP, Static IP |
| Support automatic access detection | |
| Supports broadband account automatic transfer | |
| Operating Mode | Wireless Router Mode |
| Universal Repeater Mode | |
| WISP Mode | |
| AP Mode | |
| DHCP Server | DHCP Server |
| DHCP Client List | |
| DHCP Reservation | |
| Virtual Server | Port Forwarding |
| DMZ Host | |
| UPnP | |
| Security | Client Filter（supports black list and white list） |
| Parental Control（supports black list and white list） | |
| Remote Web Management | |
| Firewall | Forbid UDP flood attack |
| Forbid TCP flood attack | |
| Forbid flood attack | |
| Forbid WAN PING from internet | |
| DDNS | Support DynDNS, 88ip |
| VPN | IPsec pass through |
| PPTP pass through | |
| L2TP pass through | |
| Special Features | PPPoE Username/password Clone |
| Smart WiFi Schedule | |
| Smart Power Saving | |
| Smart LED on/off | |
| Tenda Cloud | |
| Tenda App | |
| Others | IPv6 Features Supported |
| Broadband management | |
| MAC address clone | |
| System Log | |
| Backup & Restore configurations | |
| Firmware upgrade from local | |
| Temperature | Operating Temperature: 0℃ ~ 40℃ |
| Storage Temperature: -40℃ ~ 70℃. | |
| Humidity | Operating Humidity:10% ~ 90% RH non-condensing |
| Storage Humidity: 5% ~ 90%RH non-condensing. | |
| Default Settings | Default Access: tendawifi.com or //192.168.0.1 |
| Certification | CE/FCC/RoHS |
| EIRP Power (Max) | 2.400-2.4835GHz: 19.95dBm (EIRP) |
| 5.150-5.250GHz: 22.90dBm (EIRP) | |
| Package Contents | Wireless Router*1 |
| Gigabit Ethernet Cable*1 | |
| Power Adapter*1 | |
| Installation Guide*1 |
| condition | new |
|---|---|
| Shipping | Free Shipping |
